Dynamic Verification of OCaml Software

Nikolaus Huber

About me

About me

About me

About me

About me

About me

• Functional core
• Many imperative features
• References
• Mutable arrays
• I/O
• Exceptions

Infer

Astrée

...

Gospel

• Behavioural specification language
• Type invariants, function pre/post conditions, mutability, exceptions, ...
• Tool agnostic
• Cameleer
• Why3gospel
• ORTAC
• ...

Property-based testing

• Popularised by QuickCheck
• In OCaml → QCheck
• Property → bool function

		let prop (l : 'a list) : bool =
			List.rev (List.rev l) = l
		in
		let test =
			QCheck.Test.make
				QCheck.(list nat_small)
				prop
		in
		QCheck.Test.check_exn test


QCheck-STM

• QCheck + state
• closed-box, model-based state-machine testing

QCheck-STM

		type sut = int Stack.t
		type state = int list

		let init_sut () = Stack.create ()
		let init_state = []

		type cmd =
			| Push of int
			| Pop
			...

		let arb_cmd (s:state) =
			...
			oneof [
				map (fun k -> Push k) int;
				pure Pop;
				...

		let next_state (c:cmd) (s:state) = match c with
			| Push i -> i :: s
			| Pop 	 -> List.tl s
			...

		let run (c:cmd) (h:sut) = match c with
			| Push i 	-> ... Stack.push i h
			| Pop  		-> ... Stack.pop h
			...

		let postcond (c:cmd) (s:state) (r:res) = ...
			...
			| Pop, r -> r = List.hd s
			...


ORTAC

• (O)Caml (R)un(T)ime (A)ssertion (C)hecker
• Module I/F + GOSPEL => code for testing
• Plugins
• Wrapper
• Monolith
• QCheck-STM
• ...

Stack (Excerpt)

		type 'a t

		exception Empty

		val create : unit -> 'a t
		val push : 'a -> 'a t -> unit
		val pop : 'a t -> 'a
		val is_empty : 'a t -> bool


		type 'a t
		(*@ mutable model contents : 'a sequence *)


		val create : unit -> 'a t
		(*@ t = create ()
			  ensures t.contents = Sequence.empty *)


		val push : 'a -> 'a t -> unit
		(*@ push v t
				modifies t.contents
				ensures t.contents =
					Sequence.cons v (old t.contents) *)


		val is_empty : 'a t -> bool
		(*@ b = is_empty t
				ensures b = match Sequence.length t.contents with
				  | 0 -> true
				  | _ -> false *)


Configuration module

		type sut = char Stack.t

		let init_sut = Stack.create ()


Running Ortac/QCheck-STM

		ortac qcheck-stm stack.mli stack_config.ml


• Generates code for RAC
• Needs a few additional libraries to link
• dune plugin available
• Can be easily integrated into CI

		val copy : 'a t -> 'a t
		(*@ r = copy t
				ensures r.contents = t.contents *)


		val transfer : 'a t -> 'a t -> unit
		(*@ transfer t1 t2
				modifies t1.contents
				modifies t2.contents
				ensures t1.contents = Sequence.empty
				ensures t2.contents =
					(old t1.contents) ++ (old t2.contents) *)


Evaluation - Errors/Bugs found

Hashtbl

		val create : ?random:bool -> int -> ('a, 'b) t
		(** [Hashtbl.create n] creates a new empty hash table with
			initial size [n]. For best results, [n] should be on the
			order of the expected number of elements that will be in
			the table.  The table grows as needed, so [n] is just an
			initial guess. ... *)


		type ('a, 'b) t
		(*@ mutable model contents : ('a * 'b) list *)

		val create : ?random:bool -> int -> ('a, 'b) t
		(*@ h = create ?random size
				checks size >= 0
				ensures h.contents = [] *)


		Gospel specification violation in function create

		File "hashtbl.mli", line 7, characters 11-20:
			size >= 0
		when executing the following sequence of operations:

		[@@@ocaml.warning "-8"]
		open Hashtbl
		let protect f = try Ok (f ()) with e -> Error e
		let sut0 = create ~random:false 16
		let r = protect (fun () -> create ~random:true (-8))
		assert (match r with
					| Error (Invalid_argument _) -> true
					| _ -> false)
		(* returned Ok () *)


Errors found

• Documentation fix
• Hashtbl.create (initial size guess can be negative)
• 2 bugs in Varray library
• 7 bugs in Bitv library
• 3 functions with possible integer overflow
• 2 functions with possible division-by-zero
• 2 functions throwing unexpected exceptions
• ...

Thank you for listening!

Questions?

https://github.com/ocaml-gospel/ortac/

This work was partially funded by ANR grant ANR-22-CE48-0013 and Tarides.
